Havells 6A SP C‑Curve MCB – Euro‑II Series, 10kA, IS/IEC 60898‑1

Havells MCB SP C Curve 6A is a single‑pole miniature circuit breaker designed to protect circuits against overload and short‑circuit faults, especially where motors and other inductive loads are used. With a 6A current rating and C‑curve tripping characteristic, it is suitable for domestic and light commercial applications that experience moderate inrush currents, such as small motors, pumps and mixed lighting loads. The breaker conforms to IS/IEC 60898‑1 standards and, in the Euro‑II series, offers a typical breaking capacity of 10kA at 220–240V AC, providing reliable disconnection under fault conditions. It features safety terminals, precise hammer‑action mechanism and a trip‑free design so the handle cannot be held ON during a fault. Large cable terminals, dual‑position DIN‑rail clip and air‑circulation channels help ensure easy installation, cooler operation and low watt loss, improving service life and energy efficiency. Brand: Havells Application: Protection against overload and short circuit for motors and other inductive or high‑inrush loads Current rating: 6A (range for this family: 0.5A to 63A) Number of poles: Single pole (SP) Curve type: C curve (trips at about 5–10 × In) Breaking capacity: Typically 10kA (Euro‑II series) Rated voltage: About 220–240V AC, 50 Hz, single‑phase Standard/specification: IS/IEC 60898‑1 (and often IEC 60947‑2 for Euro‑II) Mounting: DIN‑rail clip, dual‑position Key features: Safety terminals, trip‑free mechanism, air‑circulation channel, padlocking facility, low power loss, 13‑plate arc chute for effective arc quenching
