Havells Euro‑II 20A SP C‑Curve MCB – 10kA, IS/IEC 60898‑1, DHMGCSPF010

Product Name Havells Euro‑II 20A SP C‑Curve MCB – 10kA, IS/IEC 60898‑1 (Model DHMGCSPF020) Item Type (Group Name) 20A Single‑Pole C‑Curve Miniature Circuit Breaker (MCB), Euro‑II Series Display Title (Optional) Havells Euro‑II 20A SP C‑Curve MCB – 1‑Pole, 10kA, 240V AC, IS/IEC 60898‑1, DHMGCSPF020 Product Description Havells Euro‑II 20A SP C‑Curve MCB is a single‑pole miniature circuit breaker designed for protection of electrical circuits against overload and short‑circuit faults in residential, commercial and light industrial installations. With a 20A current rating and C‑curve trip characteristic, it is suitable for circuits supplying mixed resistive and inductive loads such as lighting, socket outlets, pumps and small motors that draw moderate inrush currents. The breaker provides a 10kA short‑circuit breaking capacity at 240V AC and conforms to IS/IEC 60898‑1 (and typically IEC 60947‑2), ensuring reliable fault clearing and compliance with safety standards. Euro‑II features include safety terminals, an air‑circulation channel, padlocking facility, integrated label holder, large cable terminals and a 13‑plate arc chute for effective arc quenching and cooler operation. The trip‑free mechanism prevents the handle from being held ON during a fault, while the dual‑position DIN‑rail clip allows easy mounting and removal on 35 mm rails, with low watt loss helping to reduce temperature rise inside the distribution board. Brand: Havells Series: Euro‑II MCB Model / item code: DHMGCSPF020 Current rating: 20A Poles: Single pole (SP / 1‑pole) Curve type: C curve (suited for motor/inductive and general‑purpose loads) Breaking capacity: 10kA at 240V AC Rated voltage: 240–415V AC, 50 Hz Standards: IS/IEC 60898‑1 (and generally IEC 60947‑2) Application: Protection against overload and short circuit for motors and other inductive or high‑inrush current loads, plus general sub‑circuit protection Key features: Safety terminals, air‑circulation channel, padlocking facility, integrated label holder, large cable terminals, precise hammer action, 13‑plate arc chute, trip‑free mechanism, dual‑position DIN‑rail clip, low watt loss for cooler operation
