Schneider EasyPact CVS100B LV510317 100A 4P 3D MCCB – 25kA at 415V, TM‑D Trip Unit, 440V AC, IEC 60947‑2

Brand: Schneider Electric Range: EasyPact CVS100…250 Device short name: CVS100B Product type: Moulded case circuit breaker (MCCB) for distribution Poles description: 4P, protected poles 3D (3 poles protected, left neutral switched only) Rated current In: 100A at 40°C Trip unit: TM‑D, thermal‑magnetic, rating 100A, long‑time pickup adjustable 0.7–1 × In (70–100A), fixed long‑time delay, fixed instantaneous pickup around 800A ​ Network type: AC, 50/60 Hz Rated operational voltage Ue: up to 440V AC Breaking capacity Icu (IEC 60947‑2): 40kA at 220/240V AC, 25kA at 380/415V AC, 20kA at 440V AC Rated service breaking capacity Ics: up to 40kA at 220/240V AC, 25kA at 380/415V AC, 15kA at 440V AC ​ Utilisation category: Category A ​ Protection provided: Overload (thermal), short‑circuit (magnetic); optional earth‑leakage via external Vigi module (not built‑in) Mounting mode/support: Fixed, backplate mounting; front connections (top and bottom) with screw terminals ​ Rated impulse withstand voltage Uimp: 8kV ​ Mechanical endurance: around 30,000 operations ​ Electrical endurance: about 12,000 operations at 415V In ​ Connection pitch: 35 mm ​ Dimensions: Height 161 mm, width 140 mm, depth 86 mm (approx. 16.1 × 14.0 × 8.6 cm) Approx. weight: 2.2–2.6 kg depending on listing
