Schneider Electric Easy9 20A 1P MCB – 6kA, C‑Curve, 230V, DIN‑Rail Mount

The device is 18 mm wide (one DIN module) and about 81 mm high, enabling compact mounting on a 35 mm DIN rail in consumer units and MCB distribution boards. It uses tunnel/cage terminals to accept standard copper conductors and features a front toggle with contact position indication for clear ON/OFF status. Overall, this MCB is intended as an economical, reliable protective device for final sub‑circuits up to 20A in homes and small offices. Category: Miniature Circuit Breaker (MCB) Current rating: 20A Number of poles: 1P, 1 protected pole Tripping curve: C curve Breaking capacity: 6kA at 230V AC, IEC/EN 60898‑1 Trip unit: Thermal‑magnetic Network type: AC, 50/60 Hz Mounting: Clip‑on, 35 mm DIN rail Approx. dimensions: Width 18 mm, height about 81–82 mm, depth about 72–78 mm (depending on region variant)
