Schneider Electric Easy9 25A 1P MCB – 6kA, C‑Curve, 230V, DIN‑Rail Mount

Easy9‑25A 1P MCB 6kA C Curve is a single‑pole miniature circuit breaker from Schneider Electric’s Easy9 range for residential and small commercial distribution boards. It provides thermal‑magnetic protection against overload and short‑circuit faults on 230V AC circuits up to 25A, with a C‑curve trip characteristic suitable for general‑purpose and moderately inductive loads like lighting and socket circuits. The device has a rated short‑circuit breaking capacity of 6kA at 230V AC as per IEC 60898‑1, making it appropriate for typical low‑voltage installations. It is 18 mm wide (one DIN module) and about 81 mm high, allowing compact installation on a 35 mm DIN rail in consumer units and MCB distribution boards. Cage‑type terminals accept commonly used copper conductors, and the front toggle clearly indicates ON/OFF status for safe operation. Overall, this MCB is intended as an economical but reliable protective device for final sub‑circuits in homes and small offices. Range name: Easy9 Category: Miniature Circuit Breaker (MCB) Current rating: 25A Number of poles: 1P, 1 protected pole Tripping curve: C curve (magnetic trip at approx. 5–10 × In) Breaking capacity: 6kA at 230V AC, IEC 60898‑1 Network type: AC, 50/60 Hz Trip unit: Thermal‑magnetic Mounting: 35 mm DIN‑rail mount Width: 18 mm; height: about 81 mm ​ Tax class (India): GST‑18
